Easy to read
Read all the important diving details at a glance from a clear, legible screen. Large numbers and texts with high contrast colors are easy to see even in murky waters or when diving at night time.
Grows with you
EON Core is ready out-of-the-box, but you can modify the features as you like to fit your own needs with the Suunto CustomDisplay™. Choose from different view styles and select the dive details you want to see. Updatable software makes EON Core a loyal diving partner for years to come.
Compact and comfortable
The lightweight, compact composite case with an elastomer strap or bungee is comfortable on any size of a wrist. Press large buttons easily with or without gloves. Conveniently re-charge the battery through USB
Connect and transfer
Connect wirelessly with up to 10 Suunto Tank PODs to display tank and gas information. Transfer your dive logs easily over Bluetooth to your mobile phone. In Suunto app you can relive your dives, add photos and share your underwater adventures with friends.
EASY TO READ
COMPACT AND COMFORTABLE
GROWS WITH YOU
CONNECT AND TRANSFER
FOR ALL DIVING
| Bezel material: | Composite |
|---|---|
| Glass material: | Mineral crystal |
| Case material: | Reinforced composite |
| Strap material: | Elastomer |
| Weight | 154 g / 5.43 oz |
| Water resistance | 80 m (ISO 6425, EN 13319) |
| Firmware upgradable | |
| Battery type | rechargeable lithium-ion |
| Time, date | |
| Stopwatch timer | |
| Languages | EN, CS, DA, DE, ES, FI, FR, IT, JA, KO, NL, NO, PL, PT, RU, SV, ZH |
| Backlight | LED |
| Configurable backlight | |
| Flip display | |
| Display type | color TFT |
| Display resolution | 320 x 240 |
| Battery indicator | icon + dive hours remaining |
| Metric and imperial units | |
| Alarm clock | 1 daily alarm |
| Smartphone compatibility |
Most common models supported, check here for detailed compatibility list |
|---|---|
| Connectivity (between devices) |
inductive (Tank Pod), Bluetooth Smart |
| Compatible with DM5 | |
| Log transfer |
Bluetooth Smart / USB cable |
| Compatible with Suunto app |
| Digital compass | |
|---|---|
| Tilt compensation | up to 45° |
| Declination correction | |
| Direction scale | degrees |
| Needle | compass rose |
| Globally balanced | |
| Bearing lock with direction indicator | |
| Compass accuracy | +/- 15° |
| Compass resolution | 1° |
| Operating temperature | 0° C to +40° C / +32° F to +104° F |
|---|---|
| Storage temperature | -20 ° C to +50 ° C / -4° F to +122° F |
| Recommended charging temperature | 0° C to +35° C / +32° F to +95° F |
| Maximum operating depth (EN 13319) | 80m |
|---|---|
| Rebreather (CCR), fixed point | |
| Trimix (mixed gas) | |
| Nitrox (and air) | |
| Gauge | |
| Dive time | 0 to 999 min |
| Surface time | 0 to 100 h |
| No fly time | |
| Safety Stop | |
| Deep Stop | |
| Ascent time display | 0 - 999 min ( > after 999) |
| CNS/OTU (OLF) calculation | |
| Wireless air integration | optional (up to 10 different tanks with Suunto Tank POD) |
| Gas time | |
| Gas consumption (real-time) | |
| Decompression model |
Suunto Fused™ RGBM |
| Custom displays | 4 per dive mode |
| Personal adjustment |
P+2, P+1, P0, P-1, P-2 |
| Altitude adjustment | 0 - 300 m / 300 -1500 m / 1500 - 3000 m |
| Gases | up to 10 gases (Oxygen 5 - 99% / Helium 0 -95%) |
| Gas max pO2 | manual 0.5 - 1.6 / fixed 1.6 |
| Gas switching | |
| Timer | |
| No-decompression planner | |
| Logbook memory |
200h or 400 dives which comes first |
| Logbook bookmarks | |
| Logbook sampling rates | 10 s |
| Dive History | lifetime |
| Visual style |
Classic/Graphical/Prominent |
| Too fast ascent | |
|---|---|
| Decompression ceiling violation | |
| Deepstop violation | |
| CNS/OTU (OLF) 80% / 100% | |
| Switch gas (better gas is available) | |
| Diluent switched automatically | |
| Diluent high pO2 | |
| Diluent low pO2 | |
| ICD warning | |
| Dive time | |
| Gas time | |
| High pO2 (hyperoxic) | |
| Low pO2 (hypoxic) | |
| Maximum depth | |
| Tank pressure |
| Diluents | up to 10 diluents (Oxygen 5 - 99% / Helium 0 - 95%) |
|---|---|
| Bailout | |
| High/low setpoints | |
| Custom setpoint | |
| Manual/automatic setpoint switching |
| Temperature | |
|---|---|
| Temperature display range | -20° C to +50° C (+/- 2° C) / -9° C to +122° F (+/- 3.6° F) |
| Temperature resolution | 1° C / 1.5° F |
